Welding Equipments
Pedal Opeated Spot Welding Machine
Pedal Opeated Spot Welding Machine from Pathak Machines is designed for precision engineering, fabrication support and dependable industrial production. As a trusted Supplier in Orissa and Manufacturer in Odisha, it supports practical handling with dependable industrial output. The machine is suitable for manufacturing units, workshops, maintenance teams and industrial plants, offering dependable build quality and practical industrial performance.
Order By Phone
Shipping Information Usually dispatched With In business days
Overview
Built for dependable industrial performance
Product Overview: Pedal Opeated Spot Welding Machine is a professional welding equipments solution from Pathak Machines, developed for precision engineering, fabrication support and dependable industrial production. It is created for industries that need reliable output, practical operation and dependable engineering machinery from a trusted Manufacturer and Supplier in Odisha and Orissa.
Key Features: This machine is manufactured to support tough usage, regular maintenance and continuous production schedules. Its operating design focuses on heavy-duty construction, smooth operation and long service reliability, making it suitable for regular industrial use where accuracy, repeatability and safe handling are important. Pathak Industries gives attention to build quality, alignment, usability and long service support.
Applications and Benefits: The Pedal Opeated Spot Welding Machine is used across manufacturing units, workshops, maintenance teams and industrial plants. It helps teams improve throughput while maintaining consistent quality and helps production teams handle work with better control, reduced downtime and improved confidence. Whether used for batch work, maintenance jobs or continuous shop-floor activity, it delivers practical value for modern industrial solutions.
Industries Served and Why Choose Pathak Machines: This product is suitable for component manufacturing, plant maintenance, industrial contracting and engineering operations. Pathak Machines is known as an Industrial Machine Manufacturer and Industrial Equipment Supplier serving Odisha, Orissa and wider Indian markets. Customers choose Pathak Industries for robust construction, application-focused guidance, responsive support and machinery built for dependable performance in real production conditions.
Specifications
Technical details and working capacities
| MODEL | PSW-8 | PSW- 10 | PSW-12 | PSW-15 | PSW20 |
| KVA Rating @50% duty Cycle (KVA) | 8 | 10 | 12 | 15 | 20 |
| Input Supply (Volts) | 230 / 440 | 230 / 440 | 230 / 440 | 380 / 440 | 380 / 440 |
| Phase | 1/2 | 1/2 | 1/2 | 2 | 2 |
Single Phase (2 Lines of 3 Phase Supply) |
|||||
| Insulation Class | A (Cu.) | A (Cu.) | A (Cu.) | A (Cu.) | A(Cu.) |
| Nomination Throat Clearance (MM) | 230 | 230 | 230 | 230 | 230 |
| Throat Depth (MM) | 450 | 450 | 450 | 450 | 450 |
| Max.Electrode Stroke (MM) | 40 | 40 | 40 | 40 | 40 |
| Nominal Electrode Force (Approx kg.) | 100 | 100 | 100 | 100 | 100 |
| Max.Available short circuit current (k.Amps.) | 7.5 | 7.5 | 8 | 10 | 12 |
Welding Range |
|||||
| Mild Steel Thickness (MM) | 2.0 0.3 | 2.5 0.3 | 3.0 0.4 | 3.0 0.5 | 3.5 0.6 |
| Brass Steel Thickness (MM) | 0.9 0.1 | 1.1 0.2 | 1.2 0.25 | 1.5 0.3 | 2.0 0.3 |
| Stainless Steel Thickness (MM) | 1.8 0.25 | 2.2 0. 28 | 2.4 0.32 | 2.4 0.35 | 3.0 0.4 |
| Cooling for Arms & Electrods | Water | Water | Water | Water | Water |
| Cooling | Nataral Air |
||||
| Approx Dimensions (HLW) MM | 1200 660 450 | 1200 660 450 | 1200 660 450 | 1200 660 450 | 1200 700 500 |
| Weight With arm Approx (KG) | 150 | 155 | 155 | 155 | 185 |
