CNC Lathe Machine

Send Email /SMS Enquiry

Order by Phone
0671-2505250

Shipping Information Usually dispatched With In business days.

	Parameter		Specification
01	Travel X Axis	:	175 mm
	Travel Y Axis	:	115 mm
	Travel Z Axis	:	115 mm
02	Table Size length X width	:	360 X 140 mm
03	Axis Control	:	Simultaneous Three Axis Control
04	Accuracy	:	5 Micron each Axis
05	Spindle
	Speed range	:	100 -2500 rpm min
	Morse Taper	:	ISO 30
	Motor Power Cap	:	0.75 HP
06	Feed rate Axis	:	2-50 mm / min
	Feed Rapid Travels	:	0 -700 mm / min
07	Control system	:	PC based 3 Axis Continuous path
08	Slides	:	Hardened & Ground Linear Guide Ways
09	Power source	:	230 V, Single Phase 50Hz
10	Software	:	Programming and operating software and manuals with courseware and project book
11	Job scaling facility and canned cycles	:	Provided
12	Accessories	:	Coolant System and chip tray Machine splash guard Voltage stabilizer Service Tool kit Machine lamp Machine vice Tool and Tool holder.
13	4 in 1 Machine User Manual containing following features:- Machine Operation Machine Maintenance Electric Circuit Diagrams Project Book	:	Provided
14	Machine Installation, Commissioning and Training	:	Provided at Site
15	Warranty	:	1 Year
16	AMC after Warranty period	:	Provided

OPTIONAL ACCESSORIES	STANDARD ACCESSORIES	APPLICATIONS
	1. ISO standard Rt. Hand tool holder with set of Interchangeable Ceramic tool bits.
	2. Flange puller
	3. Coolant Pump
	4. Optional Accessories
	5. Set of Collets with draw-bar, Tail stock & Drill Chuck
	6. ISO standard Neutral Tool Holder.
	7. The MCI 10 Trainer Lathe is designed to provide a versatile PC-AT based CNC system at an affordable cost. Simultaneous 2-axis control
	8. enables linear and multi-quadrant circular interpolation. Several part programs are provided to demonstrate lacing, turning, taper cutting,
