    Pillar Drill Machine

    PRICE: ON REQUEST

    Order by Phone
    0671-2505250

    Shipping Information Usually dispatched With In business days.

    Technical Specifications

    Specification Pillar Drill Machine  HPD – 20
    Tilting working table Upto 360°
    Drilling capacity 20 mm
    Pillar Diameter 74.30 mm
    Spindle nose to table distance 650 mm
    Distance from spindle nose to base distance 900 mm
    Distance from spindle center to pillar surface 200 mm ( MAX )
    Table Travel 200 mm
    Taper in spindle MT -2
    Number of speed 8 Speed
    Range of Speed (RPM) 80 to 3500
    Table Size (in mm) 260 x 260
    Base size (Machined Area mm) 470 x 320
    Overall Base Size (in mm) 490 x 310
    Spindle Travel 130 mm
    Pillar Length 1170 mm
    Overall height with pulley guard 1420 mm
    V-Belt section A – 44″
    Weight (Approx.) 110 kg.
    Motor1440 RPM 3 Phase440 volts 0.5 HP
    Shipping Wooden Case  Inner Size LxWxH
    (in mm)
    660x380x1140 mm
    Specification Pillar Drill Machine  HPD – 25
    Tilting working table FIXED
    Drilling capacity 25 mm
    Pillar Diameter 92 mm
    Spindle nose to table distance 660 mm
    Distance from spindle nose to base distance 1045 mm
    Distance from spindle center to pillar surface 250 mm ( MAX )
    Table Travel 480 mm
    Taper in spindle MT – 3
    Number of speed 8 Speed
    Range of Speed (RPM) 130 to 2600
    Table Size (in mm) 330 x 330
    Base size (Machined Area mm) 365 x 575
    Overall Base Size (in mm) 370 x 580
    Spindle Travel 180 mm
    Pillar Length 1410 mm
    Overall height with pulley guard 1730 mm
    V-Belt section B – 52″
    Weight (Approx.) 225 kg.
    Motor1440 RPM 3 Phase440 volts 1 HP
    Shipping Wooden Case Inner Size LxWxH
    (in mm)
    850x450x1770 mm
    Specification Pillar Drill Machine  HPD-40
    Tilting working table FIXED
    Drilling capacity 40 mm
    Pillar Diameter 135 mm
    Spindle nose to table distance 495 mm
    Distance from spindle nose to base distance 1000 mm
    Auto feed speed (applies to PSL-40A only) 0.04 or 0.08
    Distance from spindle center to pillar surface 380 mm ( MAX )
    Table Travel 500 mm
    Taper in spindle MT – 4
    Number of speed 8 Speed
    Range of Speed (RPM) 60 to 2000
    Table Size (in mm) 490 x 490
    Base size (Machined Area mm) 820 x 490
    Overall Base Size (in mm) 825 x 495
    Spindle Travel 250 mm
    Pillar Length 1475 mm
    Overall height with pulley guard 1840 mm
    V-Belt section B – 74″
    Weight (Approx.) 500 kg.
    Motor1440 RPM 3 Phase440 volts 2 HP
    Shipping Wooden Case  Inner Size LxWxH
    (in mm)
    1200x540x1880 mm
    OPTIONAL ACCESSORIES STANDARD ACCESSORIES APPLICATIONS
    1. Electric Motor 1. AMotor Pulley 1. Tool Rooms
    2. R & F Switch 2. Tapper Drift 2. Educational Institutes
    3. Drill Chuck * Arbour / Slive 3. Manual Book 3. Workshops
    4. Key-way Compound Slide 4. Drill-bit angle gauge 4. Rolling Mills Etc
    5. Small & Medium Scale Industries
    6. Fabrication Workshops
