CNC Plasma
The standard Hi-Cut package contains:
Longitudinal rails frame
Transversal Beam
Central Unit
Universal Torch Holder
Oxy-fuel touch Assembly
Tips for Oxy-propane
All necessary electrical cables
Memory Key
Fast CAM software (Basic Version)
User’s manual
The following accessories may be ordered:
Twin oxy-fuel hose
Acetylene tip
Fast CAM professional version
Plasma Cutters
Cutting Table
Easy to start program and nest:
Drawing made by the provided FastCAM software is automatically converted into a cutting program. The FastCAM drawing of part is prepared, nested and directly transformed into cutting-required G-code file after suitable selection of programming parameters. The G-code file is then stored from the PC to a memory key which will be plugged in the USB port of Hi-cut. The file is loaded and then makes the cutting start. Drawing made using AutoCAD are translated into cutting program by FastCAM and are directly usable by HI-CUT1
Convenient and flexible file transmission:
Supporting USB Port, files can be transmitted easily from a PC to the machine. The after sale technical support is provided by our online after sale department on 24 hours availability basis.
24HRS. TECHNICAL SUPPORT
Technical support and product maintenance of FastCam software will be provided by international of FastCam from the USA, Australia.
PRICE: ON REQUEST
Order by Phone
0671-2505250
Shipping Information Usually dispatched With In business days.
Surface Grinding Machine
| Model | HI-CUT1 |
|---|---|
| Input Power | 220V / 110V 50-60 Hz |
| Rated Power | 180W |
| Efficient Cutting Range | X Axis: 1200mm (47”) – Y Axis: 2000mm (78”) Y Axis: Can be extended till 5500mm (216”) |
| Dimensions of LCD | 5.7” |
| Cutting Thickness (Flame) | 0.2”- 5.9” (6-150mm) |
| Cutting Thickness (Plasma) | Depends upon plasma source |
| Weight | 70.5 kg (156lbs) |
| Type of Cutter | Oxy- Fuel or Plasma |
| Applicable cutting Fuel | Acetylene, Propane, LPG, Gasoline |
| Fuel Pressure | Max. 0.1MPa (14.5 PSI) |
| Oxygen Pressure | Max. 1.5MPa (218 PSI) |
| Cutting software | Fast Cam |
| Z Axis Manually Adjustable, Inclinable |
| OPTIONAL ACCESSORIES | STANDARD ACCESSORIES | APPLICATIONS |
|---|---|---|
| HI-CUT1 an ideal equipment for the small and medium –scale enterprises, HI-CUT1 compact CNC cutting Machine can be widely applied in industries such as automobile, shipyard, locomotive, petrochemical, aviation and aerospace, boiler and pressure vessel, machinery, decoration and large-size metallic signs. The cutting and blanking of metal plates such as carbon steel (flame cutting) and stainless steel, copper, aluminum etc. (plasma cutting) can all be performed by HI-CUT. It is a replacement of hand-held flame torch, hand-held plasma cutter, profile and pantographic shape cutting machines. |
